Eiettore a vuoto
Serie ZPS
- Potente
- Flusso di volume: 171 l/min - 175 l/min
- Consumo d'aria: 197 l/min - 350 l/min
- Livello di vuoto max.: -87 kPa
- Grafico a occhio per il settore alimentare
Questa soluzione è ideale per le applicazioni che richiedono un'elevata portata e un basso livello di vuoto. Inoltre, consente di movimentare i pezzi senza pressione, il che è particolarmente utile per i prodotti alimentari.
Livello di vuoto max.
Flusso di volume [l/min]
Peso [kg]
Dimensioni costruttive: ZPS10 | ||||
| N° ordine | Livello di vuoto max. | Flusso di volume | Consumo d'aria a 2,2 bar | |
|---|---|---|---|---|
| ZPS10-1B20-A-H12 | -35 [kPa] | 175 [l/min] | ||
| ZPS10-1B20-A-H19 | -35 [kPa] | 175 [l/min] | ||
| ZPS10-1B20-A-S | -35 [kPa] | 175 [l/min] | ||
| ZPS10-1B20-SS-H12 | -35 [kPa] | 175 [l/min] | ||
| ZPS10-1B20-SS-H19 | -35 [kPa] | 175 [l/min] | ||
| ZPS10-1B20-SS-S | -35 [kPa] | 175 [l/min] | ||
| ZPS10-1B40-A-H12 | -35 [kPa] | 175 [l/min] | ||
| ZPS10-1B40-A-H19 | -35 [kPa] | 175 [l/min] | ||
| ZPS10-1B40-A-S | -35 [kPa] | 175 [l/min] | ||
| ZPS10-1B40-SS-H12 | -35 [kPa] | 175 [l/min] | ||
| ZPS10-1B40-SS-H19 | -35 [kPa] | 175 [l/min] | ||
| ZPS10-1B40-SS-S | -35 [kPa] | 175 [l/min] | ||
| ZPS10-2B20-A-H12 | -35 [kPa] | 175 [l/min] | ||
| ZPS10-2B20-A-H19 | -35 [kPa] | 175 [l/min] | ||
| ZPS10-2B20-A-S | -35 [kPa] | 175 [l/min] | ||
| ZPS10-2B20-SS-H12 | -35 [kPa] | 175 [l/min] | ||
| ZPS10-2B20-SS-H19 | -35 [kPa] | 175 [l/min] | ||
| ZPS10-2B20-SS-S | -35 [kPa] | 175 [l/min] | ||
| ZPS10-2B40-A-H12 | -35 [kPa] | 175 [l/min] | ||
| ZPS10-2B40-A-H19 | -35 [kPa] | 175 [l/min] | ||
| ZPS10-2B40-A-S | -35 [kPa] | 175 [l/min] | ||
| ZPS10-2B40-SS-H12 | -35 [kPa] | 175 [l/min] | ||
| ZPS10-2B40-SS-H19 | -35 [kPa] | 175 [l/min] | ||
| ZPS10-2B40-SS-S | -35 [kPa] | 175 [l/min] | ||
Dimensioni costruttive: ZPS20 | ||||
| N° ordine | Livello di vuoto max. | Flusso di volume | Consumo d'aria a 2,2 bar | |
| ZPS20-1B20-A-H12 | -65 [kPa] | 174 [l/min] | ||
| ZPS20-1B20-A-H19 | -65 [kPa] | 174 [l/min] | ||
| ZPS20-1B20-A-S | -65 [kPa] | 174 [l/min] | ||
| ZPS20-1B20-SS-H12 | -65 [kPa] | 174 [l/min] | ||
| ZPS20-1B20-SS-H19 | -65 [kPa] | 174 [l/min] | ||
| ZPS20-1B20-SS-S | -65 [kPa] | 174 [l/min] | ||
| ZPS20-1B40-A-H12 | -65 [kPa] | 174 [l/min] | ||
| ZPS20-1B40-A-H19 | -65 [kPa] | 174 [l/min] | ||
| ZPS20-1B40-A-S | -65 [kPa] | 174 [l/min] | ||
| ZPS20-1B40-SS-H12 | -65 [kPa] | 174 [l/min] | ||
| ZPS20-1B40-SS-H19 | -65 [kPa] | 174 [l/min] | ||
| ZPS20-1B40-SS-S | -65 [kPa] | 174 [l/min] | ||
| ZPS20-2B20-A-H12 | -65 [kPa] | 174 [l/min] | ||
| ZPS20-2B20-A-H19 | -65 [kPa] | 174 [l/min] | ||
| ZPS20-2B20-A-S | -65 [kPa] | 174 [l/min] | ||
| ZPS20-2B20-SS-H12 | -65 [kPa] | 174 [l/min] | ||
| ZPS20-2B20-SS-H19 | -65 [kPa] | 174 [l/min] | ||
| ZPS20-2B20-SS-S | -65 [kPa] | 174 [l/min] | ||
| ZPS20-2B40-A-H12 | -65 [kPa] | 174 [l/min] | ||
| ZPS20-2B40-A-H19 | -65 [kPa] | 174 [l/min] | ||
| ZPS20-2B40-A-S | -65 [kPa] | 174 [l/min] | ||
| ZPS20-2B40-SS-H12 | -65 [kPa] | 174 [l/min] | ||
| ZPS20-2B40-SS-H19 | -65 [kPa] | 174 [l/min] | ||
| ZPS20-2B40-SS-S | -65 [kPa] | 174 [l/min] | ||
Dimensioni costruttive: ZPS30 | ||||
| N° ordine | Livello di vuoto max. | Flusso di volume | Consumo d'aria a 2,2 bar | |
| ZPS30-1B20-A-H12 | -87 [kPa] | 171 [l/min] | ||
| ZPS30-1B20-A-H19 | -87 [kPa] | 171 [l/min] | ||
| ZPS30-1B20-A-S | -87 [kPa] | 171 [l/min] | ||
| ZPS30-1B20-SS-H12 | -87 [kPa] | 171 [l/min] | ||
| ZPS30-1B20-SS-H19 | -87 [kPa] | 171 [l/min] | ||
| ZPS30-1B20-SS-S | -87 [kPa] | 171 [l/min] | ||
| ZPS30-1B40-A-H12 | -87 [kPa] | 171 [l/min] | ||
| ZPS30-1B40-A-H19 | -87 [kPa] | 171 [l/min] | ||
| ZPS30-1B40-A-S | -87 [kPa] | 171 [l/min] | ||
| ZPS30-1B40-SS-H12 | -87 [kPa] | 171 [l/min] | ||
| ZPS30-1B40-SS-H19 | -87 [kPa] | 171 [l/min] | ||
| ZPS30-1B40-SS-S | -87 [kPa] | 171 [l/min] | ||
| ZPS30-2B20-A-H12 | -87 [kPa] | 171 [l/min] | ||
| ZPS30-2B20-A-H19 | -87 [kPa] | 171 [l/min] | ||
| ZPS30-2B20-A-S | -87 [kPa] | 171 [l/min] | ||
| ZPS30-2B20-SS-H12 | -87 [kPa] | 171 [l/min] | ||
| ZPS30-2B20-SS-H19 | -87 [kPa] | 171 [l/min] | ||
| ZPS30-2B20-SS-S | -87 [kPa] | 171 [l/min] | ||
| ZPS30-2B40-A-H12 | -87 [kPa] | 171 [l/min] | ||
| ZPS30-2B40-A-H19 | -87 [kPa] | 171 [l/min] | ||
| ZPS30-2B40-A-S | -87 [kPa] | 171 [l/min] | ||
| ZPS30-2B40-SS-H12 | -87 [kPa] | 171 [l/min] | ||
| ZPS30-2B40-SS-H19 | -87 [kPa] | 171 [l/min] | ||
| ZPS30-2B40-SS-S | -87 [kPa] | 171 [l/min] | ||
